Azure Site Recovery: disaster recovery of VMware virtual machines

The solution Azure Site Recovery (ASR) protects virtual or physical systems, hosted both Hyper-V environment that VMware, automating the replication process to a secondary data center or to Microsoft Azure. With a single solution you can implement Disaster Recovery plans for heterogeneous environments orchestrating the replication process and actions needed for the successful recovery. Thanks to this solution, the DR plan will be easily available in any eventuality, even the most remote, to ensure business continuity. Recently, the solution has been expanded while also providing the ability to implement a disaster recovery strategy for Azure virtual machines, allowing you to enable replication between different regions.

In this article I'll show you how ASR can be used to replicate virtual machines in VMware environment to Azure (scenario 6 in the following figure), examining the characteristics and technical procedure to be followed. The following illustration shows all the scenarios currently covered by ASR solution:

Figure 1 – Scenarios covered by Azure Site Recovery

The replication scenario of VMware virtual machines to Azure requires the presence of the following architecture:

Figure 2 - Architecture in the replication scenario VMware to Azure

In order to activate the replication process is required the presence of at least one on-premises server on which you install the following roles:

Configuration Server: coordinates communications between the on-premises world and Azure, and manages the data replication.
Process Server: This role is installed by default with the Configuration Server, but may be provided more Process Server based on the volume of data to be replicated. It acts as a replication gateway, then receives replication data, performs an optimization through caching and compression mechanisms, provides encryption and sends them to the storage in the Azure environment. This role is also responsible to make the discovery of virtual machines on VMware systems.
Master target server: even this role is installed by default with the Configuration Server, but for deployment with a large number of systems can be more servers with this role. Take action during the failback process of resources from Azure by managing replication data.

On all virtual machines subject to the replication process is required the presence of Mobility Service, that is installed by Process Server. It is a special agent in charge of replicating the data in the virtual machine.

Following describes the process to follow to make the deployment of on-premises and Azure components required to enable replication of VMware virtual machines to Microsoft's public cloud.

The core component required on Azure side is the Recovery Service Vault within which, in the section Site Recovery, you can start the configuration process controlled by the chosen scenario.

Figure 3 – Choice of replication scenario of VMware virtual machines within the Recovery Service Vault

Then you must install on the on-premises machine the Configuration Server by following the steps listed:

Figure 4 – Steps to follow to add the Configuration Server

In this section of the Azure portal it is possible to download the Microsoft Azure Site Recovery Unified Setup and the key required for the registration of the server to the vault. Before starting the installation make sure that the machine on which you intend to install the Configuration Server be able to access the public URLs of the Azure service and that is enabled during the setup the web traffic on port 80 needed to download the MySQL component used by the solution.

The setup prompts you for the following information:

Figure 5 – Choice of roles to install

Select the first option for installing the roles Configuration Server and Process Server. The second option is useful if you need to install additional Process Server to enable a scale out deployment.

Figure 6 - Accept the license agreement by MySQL Community Server

Figure 7 - Key selection required for the registration to the Site Recovery Vault

Figure 8 - Choice of the methodology to access the Azure Services (direct or via proxy)

Figure 9 – Check to verify prerequisites

Figure 10 – Setting passwords for MySQL

Figure 11 – Further check on the presence of the required components to protect VMware VMs

Figure 12 – Choice of the installation path

Installation requires approximately 5 GB of available space, but are recommend at least 600 GB for the cache.

Figure 13 — Select the network interface and the port to use for replication traffic

Figure 14 – Summary of installation choices

Figure 15 - Setup of the different roles and components successfully completed

At the end, the setup shows the connection passphrase which is used by the Configuration Server, that is good to save with care.

Then you must configure the credentials that will be used by Azure Site Recovery to discover virtual machines in the VMware environment and for the installation of the Mobility Service on virtual machines.

Figure 16 - Definition of the credentials used by the service

After complete these steps you can select the Configuration Server from the Azure portal and then define VMware system data (vcenter or vSphere) with which to interface.

Figure 17 - Select the Configuration Server and add vCenter / vSphere host

On completion of this configuration it is necessary to wait few minutes to allow the Process Server to perform the discovery of VMware virtual machine on the specified environment.

Then you need to define the settings for the target of the replica:

On which subscription and what recovery model (ASM or ARM).
Which storage account use to host the replicated data.
vNet on which attest the replicated systems.

Figure 18 – Target replication settings

The next step involves defining the replication policy in terms of RPO (in minutes), retention of the recovery points (expressed in hours) and how often make consistent snapshot at the application level.

Figure 19 – Creation of the replication policy

Upon completion of this task is proposed to carry out the analysis of your environment using the tool Deployment Planner (available directly through the link in the Azure Portal) in order to ensure that the requirements, network resources and storage resources are sufficient to ensure the proper operation of the solution.

Figure 20 - Steps of infrastructure preparation completed successfully

After completing the infrastructure preparation steps you can activate the replication process:

Figure 21 - Source and Replica Target

Figure 22 - Selection of the virtual machines and of the related discs to be replicated

This section also specifies which account the Process Server will use to install the Mobility Service on each VMware virtual machine (account configured previously as documented in Figure 16).

Figure 23 - Replication policies selection and optionally enable Multi-VM consistency

If the "Multi-VM consistency" option will be selected it will create a Replication Group within which will be included the VMs that you want to replicate together for using shared recovery point. This option is recommended only when you need a consistency during the fail over to multiple virtual machines that deliver the same workload. Furthermore, by activating this option you should keep in mind that to activate the system failover process is necessary to set up a specific Recovery Plan and you can not enable failover for a single virtual machine.

At the end of these configurations you can activate the replication process

Figure 24 – Activation of the replication process and its result

Figure 25 - State of the replica for the VMware virtual machine

One of the biggest challenges when implementing a Disaster Recovery scenario is to have a chance to test its functionality without impacting production systems and its replication process. Equally true is that do not test properly the DR process is almost equivalent to not having it. Azure Site Recovery allow you to tests in a very simple way the Disaster Recovery procedure to assess the effectiveness:

Figure 26 – Testing the Failover procedure

Figure 27 - Outcome of the Test Failover process

Conclusions

Being able to rely on a single solution as Azure Site Recovery that lets you enable and test procedures for business continuity in heterogeneous infrastructures, contemplating even virtual machines in VMware environment, certainly has many advantages in terms of flexibility and effectiveness. ASR makes it possible to deal with the typical obstacles encountered during the implementation of Disaster Recovery plans reducing the cost and complexity and increasing the levels of compliance. The same solution can also be used to deal with the actual migration to Azure with minimal impact on end users thanks to nearly zero application downtime.

Azure Backup: the System State protection in the Cloud

The ability to protect the System State of Windows Server machines directly in Azure using the Azure Backup Agent was recently included. This feature was in preview for a few months and now it is available to be used in production environments. In this article I'll show you how you can protect with Azure Backup the System State of the machines, analyzing the characteristics and the benefits brought by this new feature.

The Azure Backup Agent allows you to save files, folders and thanks to the incorporation of the System State are covered by the protection of Windows Server machines the following components:

Boot files, including system files, and all files protected by Windows File Protection (WFP).
Active Directory and Sysvol (on domain controllers).
The registry.
IIS metabase (on Web Server IIS machines): includes IIS configurations and web sites hosted by the web server.
Database cluster (on cluster nodes).
Certificate Services (on the certification authority).
Information about the Performance counters.
Component Services Class registration database.

Thanks to the incorporation of the System State, Azure Backup becomes ideal for protection strategies of Active Directory, File Server and IIS Web Server.

Figure 1 – Protection of System State in Azure

This solution is supported starting with Windows Server 2008 R2 to Windows Server 2016.

To enable this type of protection is necessary to create within the subscription Azure a Recovery Service Vault, install the Azure Backup Agent on Windows Server machine and complete its registration by following the steps shown in the following diagram:

Figure 2 - Activation steps for the protection with Azure Backup

By accessing the Azure portal and selecting the Recovery Service Vault, within which you want to include the protection, in the Backup section appears the possibility of protecting the System State for workloads running On-Premises:

Figure 3 – Selection of System State as a component to be protected

By selecting the button "Prepare Infrastructure" it lists the necessary steps to protect the System State of the machines:

Figure 4 – Steps for preparing the infrastructure

From the panel above you need to download the Recovery Service Agent installation setup and the Vault credentials.

The installation of the agent (MARSAgentInstaller.exe) is very fast and consists of the following steps:

Figure 5 - Selecting the installation folder and the cache location

In the cache location it is advisable to have as free space at least 5% of protected data.

Figure 6 – Configuration of proxy system for Internet access

Figure 7 – Check the requirements and installation

Figure 8 – Initiation of the process of registration with the Recovery Service Vault

Figure 9 – Selection of login credentials to the vault

Figure 10 - Generate and save the passphrase

The Passphrase is used to encrypt and decrypt the backups, it is never sent to Azure, it is not recoverable in any way by Microsoft support personnel and it is essential to be able to perform restore operations, so you must keep it very carefully.

Figure 11 – Registration successfully

From Microsoft Azure Backup console, you can schedule a backup and for servers, in the selection of items to protect, there is the System State:

Figure 12 - Selection of the System State Protection

Figure 13 - Settings on the frequency of the backup

Figure 14 - Definition of the retention rules

Figure 15 - Final Step, activation of the System State backup

System State protection can also be automated with PowerShell. You also have the possibility to consult easily the backup jobs directly from the Azure portal, and you can configure notifications to be notified in case of failure of protection jobs.

The offsite backups is ensured with this solution without investing in infrastructure costs and saving time in operational activities. It is also good to keep in mind that the cost of this solution are really beneficial, in fact, typically the size of the System State for a single machine is significantly less than 50 GB then the System State protection pricing level falls within the lower cost band specified for the instances protected with Azure Backup. For more details on the cost of the solution you can consult the Azure Backup pricing page. No cost for any restore operations is also required.

Conclusions

The System State for Windows Server machines is a critical component that should be saved for a proper and effective strategy to protect its infrastructure. Azure Backup due to its defined approach cloud-first extend their potential enabling you to protect the System State of the machines easily, securely and with low costs. To try Azure Backup and other Azure services you can create a Azure free Account.

Azure Site Recovery: disaster recovery of Virtual Machines in Azure

In azure, there is the possibility of using Azure Site Recovery (ASR) to implement easily an efficient disaster recovery strategy by enabling replication of virtual machines among different regions of Azure. Although in Azure are present integrated mechanisms to deal with localized hardware failures, it may be appropriate to implement a solution that can ensure applications compliance , performed on virtual machines in Azure, against both catastrophic events, such as earthquakes or hurricanes, that software issues that may impact on the functioning of an entire region of Azure. This article will show you how to configure a virtual machine replication and how to enable a disaster recovery scenario.

This feature has been defined one-click replication because of its simplicity, it is currently in public preview and it is usable in all the Azure regions where ASR is available.

Before you enable this functionality is essential to ensure that the necessary requirements are met and to do that you can see the compatibility matrix for the replication scenario of virtual machines among different regions.

By accessing the Azure Portal it is possible to select the virtual machine that you intend to replicate and perform the configuration in the section Disaster recovery:

Figure 1 – Disaster Recovery Section of the VM

Selecting Disaster Recovery shows the following configuration panel:

Figure 2 – VM replication configuration panel

The first required parameter is the target region where you want to replicate the virtual machine. The replication activation process also create the necessary Azure artifacts (Resource Group, Availability Set if used by the selected VM, Virtual Network and Storage accounts) or you can select them at will if they were created earlier.

Figure 3 – The resources needed in the region target

The replication process also requires the presence of a Cache Storage Accounts in the source region that is used as a temporary repository to store changes before they are reported in the storage account defined in the target region. This is done to minimize the impact on production applications that reside on the replicated VM.

Figure 4 - Cache Storage Account in the replication process

Always in the configuration panel is required which is proposed Vault Recovery Services use creating a replication policy that defines the recovery point retention and the rate at which consistent snapshots are made at the application level.

By selecting Enable Replication will begin the creation process of Azure resources required, the VM is registered in the selected Recovery Services Vault and replication process is activated.

The Disaster Recovery section lists details about the replication and it is possible to perform a failover or a test failover:

Figure 5 - Details relating to the replication process of the VM and activation of the failover process

The procedure Test Failover Specifies which recovery point using between: latest, latest processed, latest app-consistent or custom. In addition it is possible to select in which virtual network attest the virtual machine during the test failover in order to perform the test without generating any impact on the production systems.

Figure 6 – Test Failover of a VM

Similar the Failover panel that allows you to specify only which recovery point to use as the network on which attest the machine has already been defined in the configuration phase.

Figure 7 – Failover of a VM

Only when you start the Failover process affected virtual machines are created on the target resource group, attested to the target vNet and configured in the availability set appropriate when used.

Figure 8 – Failover process

Conclusions

Thanks to this new feature introduced in Azure Site Recovery it is possible to activate with ease replication of virtual machines in different Azure regions, without the necessity of having expensive secondary infrastructure to activate a disaster recovery plan.

What's New in Azure Automation: Inventory, Change Tracking and Update Management

In Azure Autiomation were recently introduced new features, currently in preview, which make it possible to manage the distribution of updates, collect inventory information about the applications installed on the systems and keep track of changes made on the machines. This article will show you how to configure the Azure Automation Account to take advantage of these new features and it will show their main characteristics.

In order to use each of these features it is necessary that the Automation Account is associated with a Log Analytics Wokspace.

If the Automation Account where you want to enable these new features is not linked to any Workspace of Log Analytics is requested, in the process of activation, the binding to an existing Workspace or it propose the creation of a new Workspace:

Figure 1 - Association of Automation Account to Log Analytics Workspace

The capabilities of Change Tracking and Inventory are enabled simultaneously by the Azure portal and at the end of the activation will appear the following notification:

Figure 2 – Notification after enabling Change Tracking and Inventory features

For enabling Update management you will need to perform the same operation.

Figure 3 – Enabling the Update Management feature

At the end of these activities in the Log Analytics Workspace will be present the following solution:

Figure 4 – Solution added in Log Analytics

After the completion of the activation, the solution begins to show the data of machines already connected to the OMS Workspace associated with the Automation Account. You could also get the onboarding by further machines directly from the relevant sections of the Azure Portal:

Figure 5 - Adding additional systems

This process requires the installation of the OMS agent on systems and can be done either on Windows and Linux. If the machines are on the Azure fabric the OMS agent installation process is integrated and can happen quickly with a simple click from the Azure Portal. Otherwise you can still associate the systems by manually installing the OMS agent, independently from their location (on-premises or others cloud).

For the functionality of Inventory and Change Tracking you can access the settings (common among the two solutions) to customize the registry key information, the files under Windows and Linux that you plan to inventory and monitor:

Figure 6 – Edit your settings

Figure 7 - Personalization of the configuration

Inventory

This feature allows you to retrieve inventory information relating to: installed software, files, Windows Registry keys, Windows Services and Linux Daemons. All this can be accessed easily directly from the Azure portal and it is possible to apply search filters:

Figure 8 - Search the inventory data

Change Tracking

The functionality of Change Tracking monitors changes made to systems relatively to Daemons, File, Registry, software and services on Windows . This feature can be very useful to diagnose specific problems and to enable alerts against unexpected changes.

Figure 9 - Consultation of changes

By accessing the Log Analytics console you can also carry out more targeted searches:

Figure 10 – Log Search Analytics

Also in the Change Tracking there is the possibility to connect theAzure Activity Log of an Azure subscription to collect also changes you make in Azure side.

Figure 11 – Azure Activity Log connection

Update Management

The solution of Update Management allows a total visibility on the update compliance for both Windows and Linux systems:

Figure 12 - Global status of compliance of the updates on managed systems

Using the search panel you can quickly identify missing updates:

Figure 13 – Identify missing updates

The solution is not only very useful for consultation, It also allows you to schedule the deployment to install the updates within a specific maintenance window.

Figure 14 – Deplyment schedule

Very soon, even the ability to deploy on Linux systems. Among the features offered there is the ability to exclude specific updates from the deployment.

Figure 15 - Deployment Settings

Scheduled deployments and their execution status can be monitored in real time directly from the Azure Portal:

Figure 16 – List of scheduled update deployments

Figure 17 – Update Deployment in progress

Figure 18 – Update Deployment successfully completed

Selecting the deployment completed you will be sent to a well-structured and easy-to-use dashboard that allows you to check the details of the deployment:

Figure 19 – Deployment dashboard

Also useful the ability to retrieve logs that are related to deployment for troubleshooting purposes.

Conclusions

These are features that give you the ability to control and manage easily, and efficiently environments composed of few units in the cloud up to contemplate hybrid scenarios with a large number of systems. These features are currently in preview therefore intended to further expand their potential. In particular the functionality of Update Management to manage and orchestrate the updates deployment in complex environments in an efficient and flexible way will have to evolve, but it is definitely in a good point of the develop. For more details of Azure Automation I invite you to consult official documentation.

How to create a Docker environment in Azure using VM Extension

Docker is a software platform that allows you to create, manage and execute isolated applications in containers. A container is nothing more than a methodology for creating software packages in a format that allows it to be run independently and isolated on a shared operating system. Unlike the virtual machine containers do not include a complete operating system, but only the libraries and settings needed to run the software. Therefore there are a series of advantages in terms of size, speed, portability and resource management.


Figure 1 – Diagram of containers

In the world of Microsoft Azure there are different configuration and use possibilities about Docker containers that I list synthetically:

VM Extension: through a specific Extension you can implement Docker inside a virtual machine.
Azure Container Service: deploys quickly into a cluster environment Azure Docker Swarm, DC/OS or Kubernetes ready for production. This is the most complete solution for the orchestration of containers.
Docker EE for Azure: is a template available on the Azure Marketplace, a collaboration between Microsoft and Docker, which makes it possible to provision a clustered Docker Enterprise Edition integration with Azure VM Scale Sets, the Azure Load balancers and the Azure Storage.
Rancheros: is a Linux distribution designed to run containers available as template within the Marketplace Azure Docker.
Web App for Containers: you have the option of using containers, making the deployment in the Azure App Service managed platform as a Web App running in a Linux environment.
Azure Container Instances (currently in preview): is definitely the easiest and quickest way to run a container Docker in the Azure platform, without the need to create virtual machines, ideal in scenarios where containers blocks.
Azure Service Fabric: supports the containers in both the Windows and Linux. The platform contains natively support for Docker Wrote (currently in preview), allowing you to orchestrate applications based on containers in the Azure Service Fabric.
DC/OS on Azure: This is a managed cloud service that provides an environment for the deployment of workloads in cluster using DC/OS platform (Datacenter Operating System).

All these possibilities enable, according to the needs and to the scenario that you must implement, choosing the most appropriate deployment methodology in the container for execution environment Azure Docker.

In this article we will create a Docker environment in a Virtual Machine using the Docker Extension. Starting from a virtual machine in Azure, you can add the Docker Extension which installs and configures the daemon Docker, the client Docker and Docker Wrote.

This extension is supported for the following Linux distributions:

Ubuntu 13 or higher.
CentOS 7.1 or higher.
Red Hat Enterprise Linux (RHEL) 7.1 or higher.
CoreOS 899 or higher.

Adding the extension from the Azure Portal can be done via the following steps. The section Extensions Select the virtual machine button Add:


Figure 2 – Adding Extensions to the VM from the Azure Portal

Then shows the list of Extensions available, you stand onExtension Docker and press the button Create.


Figure 3 – Selection of Extension Docker

To enable secure communication with the Docker system implemented in your Azure environment you should use certificates and keys issued by a trusted CA. If you do not have a CA to generate these certificates you can follow the instructions in section Create a CA, Server and client keys with OpenSSL present in the official documentation of Docker.


Figure 4 – Communication scheme docker by encrypted protocol TLS

The Extension wizard requires first to enter the communications port of the Engine Docker (2376 is the default port). Also the CA's certificate is requested, your Server certificate and Server Key, in base64-encoded format:


Figure 5 – Parameters required by the wizard to add the Docker VM Extension

Adding the Extension Docker takes several minutes at the end of which the virtual machine will be installing the latest stable version of Docker Engine and daemon Docker will listen on the specified port using certificates entered in the wizard.


Figure 6 – Details of the Extension Docker

In case you need to allow Docker communication from outside the vNet where is attested the VM with Docker you must configure appropriate rules in Network Security Group used:


Figure 7 – Configuration example NSG to allow communication Docker (door 2376)

At this point the Docker environment is ready to be used and from a remote client you can start the communication:


Figure 8 – Docker command run from a remote client to retrieve information

Conclusions

The Azure Docker VM extension is ideal to implement easily, in a reliably and securely mode, a dev or production Docker environment on a single virtual machine. Microsoft Azure offers a wide range of possibilities in the choice of implementation related to the Docker platform, with a lot of flexibility by letting you choose the most appropriate solution for your needs.

Log Analytics: a major update evolves the solution

Last week Microsoft began releasing what may be termed the most significant update Log Analytics from date of issue. Among the main changes introduced in the new version of Log Analytics are a powerful new query language, the introduction of the new Advanced Analytics portal and greater integration with Power BI. In this article we will see how to upgrade and the main features of the new features.

How to update Log Analytics

The upgrade process is very simple and is gradually affecting the workspace who present in all region of Azure. When the update is available for your workspace you will see a notification in the portal banner OMS or directly in the Log Analytics of the portal Azure:

Figure 1 – Banners that notifies the availability of Log Analytics

With a simple click on the banner leads to the following summary screen that summarizes the changes introduced by the update and that you use to start the upgrade process by selecting the appropriate button:

Figure 2 – Upgrade of Log Analytics

The upgrade must be performed by an administrator of the workspace who and the upgrade process takes a few minutes, at the end of which all artifacts like saved searches, the alert rule, computer groups and views created by using the View Designer are automatically converted to the new language of Log Analytics. The research included in the solution are not converted automatically during the upgrade, but would like to convert on the fly and transparently to the user at the time of the opening of the same.

During the upgrade process creates a full backup of the workspace, useful in case there is a need to revert to the previous version. Recovery is possible directly from the portal OMS:

Figure 3 – Restore the workspace Log Analytics legacy

When this update is optional, but in the future will be forced by Microsoft by talking to advance the date of the conversion of the workspace.

New query building language

After upgrading you can take advantage of the potential of the new language for creating queries. We carry the main features:

This is a simple and easy-to-understand language where you can use constructs closer to natural language.
The output of a query can be correlated (piped) with other commands in order to create more complex queries than was possible with the previous language.
Supports the use of extended field calculated in real time and can be used to compose complex queries.
Improved advanced features that allow you to join tables based on multiple fields, inner join, outer joins and join using the extended field.
Are made available more functionality for operations involving functions based on date and time.
Use advanced algorithms for evaluation of patterns in dataset and compare different sets of data.
Supports inserting comments in queries, always useful when troubleshooting and to facilitate understanding of queries written by others.

Listed above are just some of the many new features that are introduced, but for more details about the new build Log Analytics query language I invite you to consult the official site specially created that contains a complete guide, tutorials and examples.

Figure 4 -Example of query written in the new language that creates a chart with daily alerts by severity

For those who already have a good familiarity with the previous generation of query language, you can use the converter that is added when upgrading your workspace and that converts queries written with language legacy in new language:

Figure 5 -Example of converting a query

Useful also Legacy to new Azure Log Analytics Query Language cheat sheet that allows you to make a quick comparison between the two languages bringing some statement of the most widely used.

Advanced Analytics Portal

With the introduction of new Advanced Analytics you can perform useful tasks when writing code that cannot be done directly from the portal of Log Analytics. Access to the portal Advanced Analytics can take place by selecting one of the following icons from Log Analytics Portal:

Figure 6 – Advanced Analytics Portal login

Thanks to this portal you get a better experience in interactive writing queries using a multi-line editing, emphasis on the context-aware syntax and a powerful integrated Viewer. The whole thing is very useful when troubleshooting, Diagnostics, trend analysis and to generate reports quickly.

Figure 7 – Query that computes and graphically displays the result of the CPU usage of a specific machine

With ease you can also create a quick visualization of the portal Advanced Analytics and make the pin in the same on a shared Azure Dashboard.

Integration with Power BI

Following this update you get even closer integration with Power BI, like Application Insights:

Figure 8 – Log Analytics integration scheme with Power BI

Through this integration you can use Power BI reports, publish and share them on PowerBI.com and enable automatic generation. For more details about I invite you to read the document Export Log Analytics data to Power BI.

Conclusions

This major upgrade of Log Analytics increases the potential of the tool allowing you to perform complex searches in a targeted and easy thanks to the new language introduced and enhances the potential of the solution due to better integration with Power BI. This new language and Advanced Analytics are already being used in Application Insights and this allows a homogeneous and consistent monitoring experience for different Azure services.

Azure Multi-Factor Authentication: Introduction to Solution

To help secure access to critical data and applications may be necessary to provide multifactor authentication which generally requires the use of at least two of the following test methods:

Something you know (typically a password).
Something that you own (a unique device and not easily duplicable, such as a phone).
A biometric recognition system that aims to identify a person based on one or more biological or behavioral characteristics (Biometrics).

Microsoft allows you to adopt a two-factor authentication solution using theAzure Multi-Factor Authentication (MFA) which provides for the adoption of a second method of verifying during the authentication process. Using this solution can be configured the following additional authentication factors:

Phone call: a call is made to the phone registered to users. In this case the user will be prompted to answer the call and to verify that you can access by pressing the button # or entering a PIN code.
Text message (SMS): is sent to the user's mobile phone an SMS that contains a pin code of 6 figures who must be entered during the authentication process.
Notified by Mobile App: the user's smartphone is sent through Mobile App a challenge that must be approved by the user to complete the authentication process.
Verification code via Mobile App: in this user's smartphone Mobile App generates a code of 6 digits each 30 seconds. The user would then put the latest code at the time that authenticates.
Party OATH token: There is the possibility to configure Azure Multi-Factor Authentication to accept verification methods provided by third-party solution.

The Azure Multi-Factor Authentication (MFA) provides for two possible deployment models:

MFA as a solution entirely in the Cloud.
MFA system installed and configured on-premises systems.

To locate the most appropriate deployment model you need to consider several aspects: What I'm putting in security, where are the users who need access to your solution and what features I really need.

What you are trying to protect?

This is the first question you should ask yourself whose answer we can already point to a specific deployment template. If indeed there is a need to enable the dual factor authentication for IIS applications that are not published by Azure App Proxy or remote access solutions (VPN or Remote Desktop Gateway) You must use the server Azure MFA implemented on-premises systems.

Figure 1 – What is secured by MFA

Where the users are located?

Another important aspect to consider is where the users are located on the basis of the Identity model adopted, come mostra la figura 2.

Figure 2 – Location of users

What features are needed?

Depending on the type of deployment selected (MFA in the cloud or local MFA) different capabilities that we could opt for a choice rather than another, come mostra la figura 3.

Figure 3 Available in two models – MFA

Requirements for the use of MFA

In order to use the Azure Multi-Factor Authentication (MFA) You must have access to a subscription Azure. If you want to test your service you can possibly use a trial subscription of Azure.

The hardware requirements as regards Multi-Factor Authentication Server Azure are minimal (200 MB disk space and 1 GB RAM), While the following software features:

Operating System: Windows Server 2008 R2 or higher
Microsoft .NET 4.0 Framework
IIS 7.0 or higher if you want to install the User Portal or the Web Service SDK

Each server MFA must be able to communicate on port 443 outbound to the following web address:

HTTPS://pfd.phonefactor.net
HTTPS://pfd2.phonefactor.net
HTTPS://css.phonefactor.net

Also if there are firewall policy to block outbound to the door 443 You must open the IP address range are documented in section "Azure Multi-Factor Authentication Server firewall requirements"the Microsoft's official documentation.

Azure Multi-Factor Authentication in the cloud

Enabling MFA cloud scenario is very simple and is done per user. To do so you need to access the service Azure Active Directory, figura 4, from the Azure Portal:

Figure 4 – Step 1: enabling MFA to the cloud

After selecting the Directory, in the "Users and groups" select "Multi-Factor Authentication":

Figure 5 – Step 2: enabling MFA to the cloud

You will be redirected to another website where selecting the specific user, figura 6, You can enable the MFA:

Figure 6 – Step 3: enabling MFA to the cloud

At this point the user is mail-enabled MFA. The same thing can also be done by selecting multiple users simultaneously and by the same portal you can configure various settings of Azure Multi-Factor Authentication. For more details about I invite you to consult Microsoft's official documentation.

The same thing can be accomplished by using the cmdlets PowerShell for Azure to which allow us to easily make enabling MFA to more users with just a few lines of code, as shown in the following example:

$users = “user1@ugisystemcenter.org”,”user2@ugisystemcenter.org”,”user3@ugisystemcenter.org”

foreach ($user $users)

{

$St = New-Object-TypeName Microsoft StrongAuthenticationRequirement. Online. Administration.

$St. Relyingparty = “*”

$St. State = "Enabled"

$is = @($St)

$User-StrongAuthenticationRequirements-MsolUser-UserPrincipalName $sta set

}

Azure Multi-Factor Authentication on-premises

On-premises deployment of Azure Multi-Factor Authentication Server requires you to download the setup installer direct from the Azure Portal. If you want to dismiss Azure Multi-Factor Authentication as a standalone service with user authentication and billing options you need to create a new Classic Azure Portal Multi-Factor Auth Provider (This feature will soon be available on the new Azure Portal).

Figure 7 — Creating new Multi-Factor Auth Providers

By selecting the button Manage you will be redirected towards the Azure Portal Multi-Factor Authentication, figura 8, from where can I donwload the setup and build the service activation credentials.

Figure 8 – Multi-Factor Authentication Server downloads and generation credentials

If you want to use the bundled license to Enterprise Mobility Suite, Azure to Premium or Enterprise Cloud Suite is not necessary to create a Multi-Factor Auth Provider but simply log into the Azure Portal Multi-Factor Authentication to directly download the setup.

After coming into possession of the setup you can install the Azure MFA Server. During setup you will be asked only the installation path, figura 9.

Figure 9 – Setup Azure MFA Server

Figure 10 – Setup Azure MFA Server

At this point you must run on Multi-Factor Authentication Server you just installed that will guide us in the activation process.

Figure 11 – Applying Multi-Factor Authentication Server

Figure 12 – Step 1: How to activate Multi-Factor Authentication Server

On the following screen you must enter the logon credentials that are generated by the Azure Portal Multi-Factor Authentication (see Figure 8).

Figure 13 – Step 2: How to activate Multi-Factor Authentication Server

After completing the first server Configuration Wizard cannot start Azure MFA, figura 14, to enable replication across multiple servers highly available service and configure the MFA Azure.

Figure 14 Multi-server MFA – Configuration Wizard

In the scenario where the Multi-Factor Authentication Server is enabled on multiple systems, the servers communicate with each other via RPC calls MFA Azure and to make sure that everything happens safely must authenticate with each other. This authentication process can occur either through specific security group membership in Active Directory (named Phone Factor Admins) is through the use of SSL certificates.

Now that you have configured the server Azure MFA there is the ability to easily import users from Active Directory, figura 15, and enable the desired authentication dual factor.

Figure 15 -Import users from Active Directory

In the scenario of use of Azure Multi-Factor Authentication (MFA) Server is good to specify that user data is saved on-premises systems and no data is stored permanently on the cloud. In fact, when a user places the process of multi-factor authentication the server Azure MFA sends the following data to the Azure Cloud service MFA to verify and reporting purposes:

Unique ID of the user (username or internal MFA server ID)
Name and surname (Optional)
Email Address (Optional)
Phone number (in the case of a telephone call or send SMS)
Token device (When using authentication via mobile app)
Authentication method
Authentication result
Name and IP address of the server Azure MFA
Client IP (If available)
Result verification (success or denied) and motivation if deny

In addition to targeted different import users from Active Directory on which you want to enable the dual factor authentication you can integrate with the Active Directory Directory service server Azure MFA and set up a targeted and scheduled import of users according to certain criteria. For details please visit the official documentation Directory integration between Active Directory and server Azure MFA.

Solution Licensing models

Azure Multi-Factor Authentication is available as standalone service, with user authentication and billing options, or in bundle with Azure Ad Premium, Enterprise Mobility Suite and Enterprise Cloud Suite. Azure Multi-Factor Authentication is available through a Microsoft Enterprise agreement, the Open Volume License program, the program Cloud Solution Provider and a Direct contract, as annual per user model. The service is also available with a model based on consumption per-user and per-authentication, billed every month according to the Azure monetary commitmen.

For more information on costs of the solution you can consult the following document: Prices of Multi-Factor Authentication.

Conclusions

Azure Multi-Factor Authentication is a simple solution to use, scalable and reliable that offers the possibility of introducing a second method of validation so that users are able to access more securely to your data and applications, both present on-premises cloud environments. For those interested in trying out the service can easily activate a subscription Azure for free by going to Free Trial of Azure.

OMS Log Analytics: How to monitor Azure networking

Inside there is the possiblity to Log Analytics of solution specifications that allow the monitor to some components of the network infrastructure that exists in Microsoft Azure.

Among these solutions are Network Performance Monitor (NPM) which was deepened in the article Monitor network performance with the new solution of OMS and that lends itself very well to monitor the health status of, the availability and accessibility of the networking of Azure. They are also currently available in the following gallery of Operations Management Suite solution that enrich the monitoring potential side OMS:

Azure Application Gateway Analytics
Azure Network Security Group Analytics

Enabling Solution

By accessing the portal who you can easily add these solutions present in the gallery by following the steps that are documented in the following article: Add Azure Log Analytics management solutions to your workspace (OMS).

Figure 1 – Analytics Solution Azure Application Gateway

Figure 2 – Analytics Solution Azure Network Security Group

Azure Application Gateway Analytics

The Azure Application Gateway is a service that you can configure in Azure environment can provide Application Delivery functionality ensuring an application layer balance 7. For more information regarding ’ Azure Application Gateway can be found in the official documentation.

In order to collect diagnostic logs in Log Analytics you need to position yourself in the Azure portal resource Application Gateway that you want to monitor, and then under Diagnostics logs Select sending the logs to the workspace Log Analytics should:

Figure 3 – Application Gateway Diagnostics settings

For the Application Gateway you can select the following log collection:

Logs that are related to active logins
Performance data
Firewall log (If the Application Gateway has the Web Application Firewall enabled)

After you complete these simple steps designed to walk easily installed solution who data sent from the platform:

Figure 4 – Azure Application Gateway Analytics Overview who Portal

All ’ within the solution, you can view a summary of the collected information and selecting the individual charts you access details about the following categories:

Application Gateway Access log
- Client and server errors in access log of Application Gateway
- Applications received by Application Gateway for now
- Failed requests per hour
- Errors detected for user agent

Figure 5 – Application Gateway Access log

Application Gateway performance
- State of health of the hosts that meet the requirements of the Application Gateway
- Failed requests of Application Gateway expressed as maximum number and with the 95 percentile

Figure 6 – Application Gateway performance

Application Gateway Firewall log

Azure Network Security Group Analytics

In Azure, you can check the network communication via the Network Security Group (NSG) which aggregates a set of rules (ACL) to allow or deny network traffic based on direction (inbound or outbound), the protocol, the address and the source port or the destination address and port. The NSG are used to control and protect the virtual network or network interfaces. For all the details about the NSG please visit the Microsoft's official documentation.

In order to collect diagnostic logs of Network Security Group in Log Analytics you need to position yourself in the Azure Portal Resource Network Security Group that you want to monitor, and then under Diagnostics logs Select sending the logs to the workspace Log Analytics should:

Figure 7 – Enabling NSG Diagnostics

Figure 8 – Diagnostic configuration NSG

On the Network Security Group you can collect the following types of logs:

Events
Counters related to rule

At this point in the OMS portal home page you can select the tile by Overview of solution Azure Network Security Group Analytics to access data from the NSG collected by platform:

Figure 9 – Azure Network Security Group Analytics Overview OMS Portal

The solution provides a summary of the logs collected by splitting them into the following categories:

Network security group blocked flows
- Rules of the Network Security Group with blocked traffic
- Network routes with traffic blocked

Figure 10 – Network security group blocked flows

Network security group allowed flows
- Rules of the Network security group with allowed traffic
- Directives of the network with traffic rules allowed

Figure 11 – Network security group allowed flows

The methodology of sending diagnostic logs of Application Gateway and Network Security Group of Azure to Log Analytics has changed recently by introducing the following advantages:

Writing the log in log Analytics takes place directly without having to use the storage account as repository. You can choose to save the diagnostic logs on the storage account, but it is not necessary for the ’ sending data to OMS.
The latency between the time of log generation and their consultation in Log Analytics has been reduced.
Have been greatly simplified the steps required to configure.
All Azure Diagnostics were harmonised as format.

Conclusions

Thanks to a more complete integration between Azure and Operations Management Suite (OMS) You can monitor and control the status of the components of the network infrastructure built on Azure comprehensively and effectively, all with simple, intuitive steps. This integration of platform Azure with OMS is surely destined to be enriched with new specific solutions for other components. For those interested to further deepen this and other features of the who remember that you can try the OMS for free.

Windows Server 2016: Configuring the Failover Cluster Witness in the Cloud

In the article Windows Server 2016: What's New in Failover Clustering all were thorough main innovations introduced with Windows Server 2016 in the failover clustering. In this article we will detail the configuration of the cluster witness in Microsoft Azure cloud, analyzing the possible scenarios and the benefits of this new feature.

Possible scenarios supported by Witness Cloud

Among the supported scenarios that lend themselves more to this type of configuration are:

Multi-site stretched cluster.
Failover Cluster that does not require shared storage (SQL Always On, Exchange DAGs, etc).
Failover Cluster composed of nodes hosted on Microsoft Azure, other public or private cloud.
Scale-out type cluster File Server.
Cluster made actually small branch-office.

Cloud Witness configuration

We begin by specifying that a requirement to configure the cluster to use the Cloud Witness is that all nodes that make up the cluster has an internet access to Azure. Cloud Witness in fact uses the HTTPS protocol (door 443) to establish a connection with the Azure blob Storage Service Account.

Configuring the subscription requires a Witness Azure Cloud in which to configure a Storage Account that will be used as Witness and Cloud on which are written the blob file used for the arbitration of the cluster.

From the Azure portal you must create a storage account type Genaral Purpose. For this purpose is incorrect, create it with a performance level standard as they are not necessary for high performance that is provided with the use of SSDS. After selecting the most suitable location and replication policies you can proceed with the process of creating.

Figure 1 – Storage Account creation

After you create your storage account you must retrieve its required access key for authentication, which will be required in configuration steps.

Figure 2 – Account Storage access keys

At this point you can change the settings of the cluster Quorum from Failover Cluster Manager by following the steps below:

Figure 3 – Failover Cluster Quorum Settings Configuration Manager

Figure 4 – Witness Quorum selection

Figure 5 – Selection of Cloud Witness

Figure 6 – Storage Account name and access key

After successful configuration will be present among the various cluster resources also Cloud Witness:

Figure 7 – Cloud Resource Witness

Azure Storage Account is created a container named msft-cloud-witness, within which there will be a single blob file that has as its name the ID I joined the cluster. This means that you can use the same Microsoft Azure Storage Account to set up the different Cloud cluster Witness, where there will be a blob file for each cluster.

Figure 8 – Container inside of the Storage Account and its contents

Advantages of using Cloud Witness

The use of Cloud Witness gets the following benefits:

Eliminates the need to have an additional separate data center for certain cluster configurations by using Microsoft Azure.
Cancels the administrative effort required to maintain an additional virtual machine cluster witness role.
Given the small amount of data written to the Storage Account service charge is ridiculous.
The same Microsoft Azure Storage Account can be used as a witness to different clusters.

Conclusions

In the Windows Server failover cluster 2016 proves ready for integration with the cloud. With the introduction of cloud cluster systems more easily is possible Witness substantially reducing overall costs for implementing, the management effort and increasing flexibility of architecture cluster.

How to migrate to Microsoft Azure systems using OMS Azure Site Recovery

In the article OMS Azure Site Recovery: solution overview Azure Site Recovery characteristics were presented and examined aspects that make it an effective and flexible solution for creating business continuity and disaster recovery strategies for your data center. In this article we will see how to use Azure Site Recovery to migrate even potentially heterogeneous environments to Microsoft Azure. Increasingly we are opposite the ’ need not only to create new virtual machines in Microsoft public cloud, but also to migrate existing systems. To perform these migrations you can adopt different strategies, including also appears Azure Site Recovery (ASR) that allows us to easily migrate virtual machines on Hyper-V, VMware, physical systems and workloads of Amazon Web Services (AWS) to Microsoft Azure.

The following table shows what is possible migration scenarios deal with ASR:

Source	Destination	Supported Guest OS type
Hyper-V 2012 R2	Microsoft Azure	All supported guest OSS in Azure
Hyper-V 2008 R2 SP1 and 2012	Microsoft Azure	Windows and Linux *
VMware and physical servers	Microsoft Azure	Windows and Linux *
Amazon Web Services (Windows AMIs)	Microsoft Azure	Windows Server 2008 R2 SP1 +

* Limited support to Windows Server 2008 R2 SP1 +, CentOS 6.4, 6.5, 6.6, Oracle Enterprise Linux 6.4, 6.5, SUSE Linux Enterprise Server 11 SP3

When you need to perform migration task is usually critically important respect the following points:

Minimize downtime of production workloads during the migration process.
Have the opportunity to test and validate the solution works in the target environment (Azure in the specific case) before the migration.
Make a single migration of data useful to the validation process for the actual migration.

With ASR this is possible by following this simple flow of operations:

Figure 1 – Migration flow with ASR

Let us now see in detail what are the operations to be carried out in a migration scenario of virtual machines on a Hyper-V host 2012 R2 to Microsoft Azure.

First, since you have to create an Azure Portal Recovery Service Vault in the subscription to which you want to migrate virtual machines:

Figure 2 – Creating Recovery Service Vault

Afterwards you must prepare l ’ order to use Azure infrastructure Site Recovery. All you can do so by following the wizard proposal from the Azure Portal:

Figure 3 – Infrastructure preparation

After declaring your migration scenario (virtual machines on Hyper-V is not managed by SCVMM to Azure), assign a name to the site Hyper-V and agree to it l ’ Hyper-V host that holds the virtual machines:

Figure 4 – Preparing Source: step 1.1

Figure 5 – Preparing Source: step 1.2

At this point you need to install on ’ Hyper-V hosts the Microsoft Azure Site Recovery. During the installation ’ you can specify a proxy server and your registration key to the vault, which you need to download it directly from the Azure Portal:

Figure 6 – Provider installation ASR

Figure 7 – Configuring access to the vault

Figure 8 – Proxy settings

Figure 9 – Registration vault ASR

After waiting a few moments on the Hyper-V server registered at Azure vault Site Recovery will appear on the Azure Portal:

Figure 10 – Preparing Source: step 2

The next step requires you to specify on which subscription Azure will create virtual machines and the deployment model (Azure Resource Manager – ARM in the following case). At this point it is important to verify that a storage account and a virtual network that attest to the virtual machines:

Figure 11 – Target Preparation

The next step is where you specify which replication policy associate with the site. If there are no previously created policy you should configure a new policy by setting the following parameters, best suited to your environment:

Figure 12 – Setting replication policy

Figure 13 – Replication policy Association

L ’ last ’ ’ steps of preparation of infrastructure require the implementation of the Capacity Planner, very useful tool to estimate bandwidth usage and storage l ’. It also allows you to evaluate a series of other aspects that you need to take well into account replication scenarios to avoid problems. The tool can be downloaded directly from the Azure Portal:

Figure 14 – Capacity planning

At this point you have completed all the configuration and preparation of ’ infrastructure and you can continue selecting which machines you want to replicate from site previously configured:

Figure 15 – Enabling replication

In the next step you can select the replicated machine configurations in terms of Resource Group, Storage Account and Virtual Network – Subnet:

Figure 16 – Target recovery settings

Between all the machines that are hosted on the ’ Hyper-V you should select to whom you want to enable replication to Azure:

Figure 17 – VMs selection to be replicated

For each selected virtual machine, you must specify the guest operating system (Windows or Linux), What ’ is the disk that holds the operating system and what data disks you want to replicate:

Figure 18 – Properties of VMs in replica

After completing the configuration of all steps will begin the replication process according to the settings configured in the policy specifies:

Figure 19 – Replication steps

After the initial replication is recommended to verify that the virtual machine still works correctly in Microsoft Azure environment by placing an “Test Failover” (point 1 Dell ’ image below) and after appropriate checks should be “Planned Failover” (point 2) to have the virtual machine available and ready to be used in production environment. When this is done can be considered completed the migration to Azure of your system and you can remove the replication configuration all ’ within the Recovery Service Vault (point 3).

Figure 20 – Finalization of the migration process

Conclusions

Azure Site Recovery with simple guided steps allows us to easily migrate, safely and with minimum downtime systems that are located in our datacenter or workloads found in Amazon Web Services (AWS) to Microsoft Azure. I remind you that the functionality of Azure Site Recovery can be tested by activating a trial of environment Operations Management Suite or of Microsoft Azure.
